Exhibition Outdoor Digital Display Screens P8 SMD Waterproof Die
Casting Aluminium
Advertising LED Display is a kind of SMD 3in1 full color LED display. It is specially
designed for the indoor High Definition shows. LED lamp adopts
standard 3in1 SMD technology. Every light unit is composed by red,
green and blue color so the colors of the display can reach 1.07
billion kinds.
Light and slim cabinet allows quick build screen in short time.
Brightness ranges from 4500-5500 Nit/sqm, suitable for indoor and
outdoor application
Cabinet Size is 640 * 640mm, unit cabinet weighs 18 kgs.
Four sets fast lock locate in left and right side, so does up and
down side, only two hands still can lock the screen.
Each cabinet has 4 big modules. Even some modules or led lamps not
working, customer can take it out and replace in short time.
>> Technical Parameters
| Model | RH-OD-DCAS8 |
| Pixel Pitch (mm) | 8 |
| Pixel density (dot/sqm) | 15625 |
| Pixel configuration | 3 in 1 SMD |
| Module size(mm) | 320*320 |
| Module pixel array | 40*40 |
| Drive mode | 1/4 scanning |
| H/V Viewing angle(Deg) | 140/140 |
| Cabinet size(mm) | 640*640 |
| Cabient resolution | 80*80 |
| Cabinet weight(Kg) | 18 |
| Cabinet material | Die-Cast Aluminum |
| Brightness (cd/sqm) | >4500 |
| Control mode | Synchronouscontrol |
| Gray scale rectification | >16384 |
| Colors(M) | 281 trillion |
| Refresh rate(Hz) | >1000 |
| Frame Rate(Hz) | 60 |
| Brightness control (level) | Manual Regulation 60 / Auto 100 |
| Supply input voltage | AC110V±15%/220V±15% |
| Supply input frequency | 50/60 |
| Cabinet max power consumption(W/cab) | 300 |
| Cabinet ave power consumption(W/cab) | 180 |
| IP Rating | IP65 |
| Working temperature(°C) | -20 ~ +50 |
| Working humidity(RH) | 10%~90% |
| Storage temperature(RH) | -40~ +80 |
| Storage humidity(RH) | 10%~90% |
| Lifespan(Hrs) | 100,000 |
>> Advantage
die-casting aluminium Advertising LED Display
Performance: Best Equality, high consistency, Big viewing angle,
can repair each led lamps
High quality: From material to finished product, from design to
produce, we control all steps, that's the guarantee of the quality
and reliability.
CE & RoHS certified
Professional manufacturer
