P6.67 Large Front Service LED Display Full Color IP65 Waterproof
22477 Dos/Sqm
>> Description
1. Outdoor pixel pitch 6.67mm; Also 8mm and 10mm are optional. LED
modules size is 320x320mm.
2. Ingress Protection IP65 level to protect the LED screen from
harsh outdoor environment
3. Brightness can reach as high as 6000nits to be visible clearly
even in sunlight.
4. Reliable quality of all components to ensure the long life span
to 100000H
5. Front service design to save structure cost and labor cost
6. High refresh rate 1920Hz and stable performance;
| Pixel Pitch | 6.67mm |
| Pixel Density | 22,477dos/sqm |
| LED Configuration | SMD2727 |
| Module Size | 320*320mm |
| Module Resolution | 48*48 dots |
| Cabinet Size | 960*960mm |
| Cabinet Resolution | 144*144dot |
| Brightness | >6000nits |
| Refresh Rate | >1920hz |
| Viewing Distance | 10-300m |
| Power Input | AC110V - 220V ±15%, 50HZ |
| Max Power Consumption | 680W/sqm |
| Ave. Power Consumption | 195W/sqm |
| Working Temperature | -20℃ - +60℃ |
| Lifespan | >100,000 Hours |
| Operating Humidity | 10% - 95% |
| Input Source | All Format (AVI, MPEG,VOB, RM, etc) |
>> Description
1. Maintenance can be conducted from either front or rear side.
This is front maintenance steel cabinet with frame and hydraulic
lever, easy to maintain from the front;
2. It can be installed without taking the space for maintenance
channel into consideration, thus improving your work efficiency.
3. Long-term Brightness:6000nits brightness(for outdoor full
colour) throughout product lifetime of the LED display
4. It Controlled with PC by synchronization, with high refresh
rate;
5. 1% spare parts provided for customers to replace defective ones
in the future.
>> Package
Fixed Installation type LED screens are packed by good quality
Flight case for better protection.
>> After Sales Service
1. 24-hour hotline service, including counselling and technical
guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Engineering technical service.
>> Technical support
1. nstallation and Maintain Manual
2. LED display system connection diagram
3. Data wire connection diagram
4. Power supply wire connection diagram
5. multi-language software Guidance
>> Warranty
We provide 2 years warranty. During the warranty time, we provide
free parts for replacement,
but we will charge you a production cost for the parts when the
warranty expires.
