Super Slim Outdoor Rental LED Display Screen Video Panel P4 For
Opening Ceremony
>> Characteristics for P4 Rental Led Display
· easily upgrade size of sign.
· user friendly computer system .
· approximate 3D image quality.
· Fast and easy to assemble and dismantle.
· Wide viewing angle ,excellent white color balance.
· High grayscale with perfect visual performance.
· High reliability and long lifespan over 100,000hrs.
>> Features
· White Balance: D50 to D93
· Extremely Thin Design
· Brightness: 2000nits(adjustable)
· 1R1G1B SMD Pixel Configuration
· Max Power Consumption:30W
· High Viewing Angle
· DC 5V Voltage Input
· High Refresh Rate Performance
| Parameter | Unit | Value |
| Brightness | cd/m² | 6000-8000 |
| Color temperature | deg.k | 6500 |
| Viewing angle - Horizontal | deg. | 140(+70/-70) |
| Viewing angle - Vertical | deg. | 140(+70/-70) |
| Cabinet Weight | kg | 22 |
| Cabinet Width | mm | 768 |
| Cabinet height | mm | 768 |
| Cabinet depth | mm | 165 |
| Cabinet area | sq. m. | 0.59 |
| Cabinet material | | Aluminium |
| Aspect ratio | | 1 : 1 |
| Ingress Protection (Front/Rear) | IP | IP40/IP20 |
| Operating temperature range | deg. C | 0 to +40 |
| Operating Humidity range | HR | 10% to 90% |
| Pixel type and configuration | R/G/B | SMD 3in1 |
| Pixel pitch | mm | 4 |
| Pixel matrix per cabinet | | 192 x 192 |
| Pixels per cabinet | | 36864 |
| Lines per meter | | 250 |
| Pixels per sq. meter | | 62500 |
| LEDs per sq. meter | | 62500 |
| Recommended minimum viewing distance | m | 4 |
| Colours | | 281 trillion |
| Gray scale | Levels | 65536 levels per colour |
| Brightness control | Levels | 100 |
| Digital processing | bit | 16 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | ≥1000 |
| Scan mode | | 1/16 duty scan drive |
| Input voltage | VAC | 110 / 240 |
| Input power frequency | Hertz | 50 or 60 |
| Input power (max/avg) | Watts per sq.m | 600/250 |
>> Advantage of the P4 rental led display
1. SMD3-in-1 technology are used for indoor LED display.
2. Wide view angle: 140 in horizonal and 140 in vertical.
3. Special design and advanced SMT technology improves the heat
dissipation
4. With high refresh rate controller, guarantee that no scan line
when taking photos.
5. Slim and lightweight design.
6. Easy for assembling and connecting with fast lock and the
connector added.
