P1.667 Indoor LED Video Wall LED Backlit Display With Nationstar SMD 1010
>> Features
1. Ultra high definition LED display, the high resolution brings
delicate display effect.
2. Wide color range, excellent color uniformity, no rainbow effect,
broadcasting strong stability.
3. Die-castting magnesium alloy cabinet, seamless, bezel-free,
size-free splicing with adjusting accuracy 0.01mm.
4. Front access die casting cabinet. can be rear and front access
cabinet.
5. Same Cabinet can be P1.56, p1.66, p1.923
| Item | parameters |
| Pixel Pitch | 1.667mm |
| Pixel Density | 360.000dos/sqm |
| LED Package | Nationstar SMD1010 |
| Module Size | 200*300mm |
| Module Resolution | 120*180dot |
| Cabinet Size | 400*300mm |
| Cabinet Resolution | 240*180dot |
| Cabinet Wegiht | 4.5kg/pc |
| Viewing Angle | 140°/140° |
| Viewing Distance | 1.9-60m |
| Power Input | AC110V - 220V ±15%, 50HZ |
| Max Power Consumption | 810W/sqm |
| Ave. Power Consumption | 200W/sqm |
| Working Temperature | -20℃ - +60℃ |
| Operating Humidity | 10% - 95% |
| Input Source | All Format (HDMI, SDI, DVI,AVI, MPEG,VOB, RM, etc) |
>> After Sales Service
1. More than 1 years warranty
2. Free factory training
3. 24/7H online support
4. Lifetime free repair and technical support

|
