Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design

    Buy cheap Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design from wholesalers

    Buy cheap Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design from wholesalers
    • Buy cheap Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design from wholesalers
    • Buy cheap Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design from wholesalers

    Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design

    Ask Lasest Price
    Brand Name : DDW
    Model Number : DDW-OCUP1010
    Certification : CE/ROHS/FCC/UL/ISO/3C
    Price : Negotiable
    Payment Terms : Bank T/T transfer, Western Union
    Supply Ability : 6000sqm/month
    Delivery Time : 7-20 days
    • Product Details
    • Company Profile

    Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design


    Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design


    >> Features


    1. Special Cabinet design to match different curve environment

    2. PCB design innovation to improve the energy-saving

    3. High quality module housing materials to enlarge the lifespan

    4. High quality waterproof : Top module ,cabinet design to ensure good waterproof function


    Itemparameter
    Pixel Pitch10mm
    Pixel Density10,000dos/sqm
    LED ConfigurationNationstar 3535
    Module Size320*160mm
    Module Resolution32*16 dots
    Cabinet Size960*960mm
    Cabinet Resolution96*96dot
    Brightness>6000nits
    Refresh Rate>1920hz
    Viewing Distance10-100m
    Power InputAC110V - 220V ±15%, 50HZ
    Max Power Consumption730W/sqm
    Ave. Power Consumptio295W/sqm
    Working Temperature-20℃ - +60℃
    Lifespan>100,000 Hours
    Input VoltageAC 110-220v, +-15%
    Input SourceAll Format (AVI, MPEG,VOB, RM, etc)

    >> Description


    1. Usage : Special Curve design of Hotel, shopping mall, 4s stroes, etc

    2. Installation : Wall-mounted, standing on floor or building Top. etc

    3. Control : Contolled by your computer ,own equipment.; or adopt wireless controller

    4. Connection : Connected to your computer or own equipment.

    5. Maintenance: Enough Free spare parts for replacement, front service easier to change.


    >> After Sales Service


    1. 1 years warranty

    2. Free factory training

    3. 24/7H online support

    4. Lifetime free repair and tech support



    Quality Outdoor Curved LED Screen 10mm Pixel Pitch Waterproof Energy Saving PCB Design for sale
