2R1G1B P16 HD LED Video Wall Full Color Lightweight LED Screen For
Advertising
1. LED video wall installed in stadium for celebrating the birthday
of Thailand Queen, with it's good LED screen performance, good
color uniformity, favorited by large people.
2. With High brightness >7500 nits make the display content
visible even under direct sunshine during daytime.
3. With light sensor for automatic brightness adjustment, make the
brightness suitable for people’s eyes and save electricity cost,
more environment Friendly.
4. Anti-UV mask, IP65 waterproof design, total outdoor use
application.
5. Large viewing angle , full color, high color uniformity and
clear image, bring you a vivid audio visual effect.
6. Epistar, Silan, Cree, Nichia, etc LED chip available.
7. With ETL, CE, EMC, TUV, ISO, ROHS, SO14001, ISO9001
certificates.
8. P4, p5, p6, p8, p10, p12, p16, p20, p25, etc indoor and outdoor
SMD, DIP all available.
9. Widely used for gas station, stations, shopping mall, square
plaza, stadium, street advertising, restaurant, shops etc.
10. NOVA, DBSTAR, LINSN, COLORLIGHT LED control system available.
>> Technical Specs
| Pixel pitch(mm) | 16 | 16 |
| LED type | DIP246 | SMD3535 |
| Pixel configuration | 1R1G1B | 1R1G1B |
| Module size(mm) | 256*128 | 256*128 |
| Module resolution | 32*16 | 32*16 |
| Cabinet size (w x h) | 1024*768mm | 1024*768mm |
| Cabinet resolution | 128*96 | 128*96 |
| Cabinet material | Steel/Al | Steel/Al |
| Cabinet weight (Kg/Sqm) | 60/52 | 60/52 |
| Brightness(cd/m2) | >7500 | > 5000 |
| Viewing angle(°) | (H)110° (V)60° | (H)140° (V)140° |
| Driving mode | 1/4 scan | 1/4 scan |
| Refresh frequency (HZ) | >1000 | >1000 |
| Operation temperature | -30°C~+60°C | -30°C~+60°C |
| Operation Humidity | 10%~99% | 10%~99% |
| Input voltage | 220V±15% /110V±15% | 220V±15% /110V±15% |
| Max Power consumption (w/m2) | <800 | <900 |
| Ave. Power consumption (w/m2) | <240 | 270 |
| Life span | 100,000hours | 100,000hours |
| Protection level | IP65 | IP65 |
1) With good lightening accordance and no mosaic
2) Can play different formats of image files, flash, WAV/MIDI,
video signal from
TV, video signal from video and other equipment
3) Different video frequency can be changed freely at the same
time, and the image
can be enlarged and reduced
4) High brightness, and can be adjustable, meets the need of
changing requirement
of customer in environment
5) Uses real pixels rather than virtual pixels, better viewing
effect
6) light and easy to install and move
