P5 SMD3528 Indoor Full Color LED Display , Seamless Indoor Led
Video Wall
P5 Indoor LED Indoor Display could be used in indoor environment
such as municipal mansion,
enterprise hall, show room, cinema, stage, with various real-time
signal sources and the SMD
encapsulation technology, its purpose is to play the important news
or events or TV program .
>> Description
* Wide viewing angles
* Seamless and lightweight
* Dynamic scanning with truer, more stable pictures( no flickering)
* Modular design for easy installation and maintenance
* Consistent uniformity over time
* Brilliant colors, breathtaking grayscales
* Operating software compatible with widely available software
* Remove the tools, improve the serviceability
>> Applications
Entertainment complexes, Churches, Restaurants, Showrooms, Casinos,
Convenience Stores, Banking, Government facilities, Theatres and
Retail outlets etc.
| Pixel pitch | 5 mm | 5 mm |
| Pixel composing | SMD3528 1R1G1B | SMD3528 1R1G1B |
| Environment | Indoor | Indoor |
| Resolution | 40000dots | 40000dots |
| Pixel composing | 1R1G1B | 1R1G1B |
| Module resolution | 32x32 dots | 64x32 dots |
| Module size | 160 mm*160mm | 320 mm*160mm |
| Cabinet resolution | 128*128 dots | 128*128 dots |
| Cabinet size | 640mm x 640 mm | 640mm x 640 mm |
| Cabinet material | Aluminum | Aluminum |
| View distance | 5meters-8meters | 5meters-8meters |
| View angle | H160°V120° | H160°V120° |
| Refresh rate | >3500 HZ | >3500 HZ |
| Maximum power consumption | 550W/M ² | 500W/M ² |
| Average power consumption | 255W/ M² | 250W/ M² |
| Scan mode | 1/16 constant current |
| Brightness | 2200 CD/ M ² |
| Power supply demand | AC220V/110V |
| Drive voltage | 5V |
| Life span | 100,000hours |
| Working Temperature | -40°C~60°C |
| Working Humidity | 10%RH~90%RH |
| Gray scale | 4096 |
| Operating platform | Windows 7, 8, 2000, XP, and Vista OS |
| Running Files | Text, Animation, Picture, Video and etc |
| Ingress Protection | IP45 IP65 |
>> Advantage
1) High and adjustable brightness can meet the demands of the
changing requirement of Customer in different environments.
2) No mosaic due to excellent flatness and nice uniformity of
light-emitting.
3) Wide viewing angles and the horizontal angle can reach 140° ,
The images effect will not change largely in the range.
4) High density make the images softer and vivider.
5) Single-lamp maintenance with low cost.
6) Good heat dissipation capability because of the unique design of
vent fan (liking shutter).
7) Environmental-friendly and energy-saving.
