Advertising Indoor Rental LED Display Boards P6.25 Full Color For
Opening Ceremony
Indoor LED Display Rental with portable cabinet,usually option
PH10,PH12mm for close viewing distance,high clear image effect .
1. Strictly selected LED chip to ensure the long life time and high
brightness of LED screen.
2. Hermetic cabinet and filling the whole of imported silica gel,
which makes our products waterproof, sun-screen, dustproof, etc.
3. Clear vivid image quality even in direct,full-on sunlight to
ensure you attracts more audience to get short ROI of your LED
display screen's investment.
4. Easy Installation & Using:easy & simple installation interface
and user friendly software to ensure the user friendly interface of
the LED display screen sytem
5. Convenient Servicing:Front and rear cabinet access make the
maintance work very convenient.
>> Technical Parameters
| Item | Specification |
| Pixel | Physical pixel pitch: 6.25 mm |
| Pixel configuration: 1R1PG1PB |
| Module | Module resolution: 40 x 40pixel | Module size: 250 x 250mm |
| Cabinet | Cabinet resolution:80x160pixel | Cabinet size:500 x 1000 x90mm |
| Cabinet :12800pixels/cabinet | Module Qty:8pcs=2(W)x4(H) |
| Material: Aluminum | Weight: 15Kg |
| Average power: 180W | Max power consumption: 350W |
Electricity parameter | Brightness: 900 - 1200 nits |
| Brightness adjusted: 100 grade by software, or by Auto-optic
induced |
| Color processing: 16bit |
| Display color: 280 trillion |
| Color temperature(k): 5000 — 9500 (choice by user) |
| Physical density: 27777 pixels/sqm |
| Whole display flatness: ≤ 1mm juncture |
| Best view distance: ≥ 5m |
| Best view angle: Horizontal ±80°, Vertical ±80° |
Storage temperature: -35℃ ~ +85℃ Working temperature: -20℃ ~ +50℃ |
| Driving method: Constant driving current Scan: 1/8 |
| Refresh frequency: ≥ 300Hz |
| Frame rate: ≥ 60Hz |
| Humidity(RH): ≤ 90~95% |
| Protection grade: IP64 |
| Working Voltage: DC 5V |
| Power supply: AC 110 / 220V, 50/60Hz |
| Average power consumption:350w/sqm |
| Max power consumption: 700w/sqm |
| MTBF: 10, 000 hours |
| Screen lifetime: 100, 000 hours |
Control system | Signal interface: DVI |
| Communication distance: Internet cable: ≤120m Fiber cable: 1000m |
| Signal transfer mode: Pixels to pixels display synchronized |
>> Advantage
1. Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person
without tool.
4. Humanized operating interface with breakdown indicator lights,
easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving
the debugging technology for nice image
